Soft pvc shoes crushing washing recycling line

Description

+86-13338664103

[email protected]

Description

01— Process flow

The main units of the recycling system:

Plastic Soft Pvc shoes recycling line is a complete engineered process to deliver fast, efficient, reliable plastic regrind. Or in short, we make “from plastic to profit” happen. Plastic soft pvc shoes are manually fed to the conveyor. The system would take care of the rest of process. Granulating Granulation is an essential step to produce uniform 12mm particles. The high-speed rotor in assist of water inflow, realizing granulating and washing at the a same time. Polytec granulator equipments a hydraulic screen cradle and hopper as well as a knife jig, which greatly reduces service time. Washing Sink-float tank stir the buoyant regrind, leaving contaminant and chemical to sink or dissolve. There is a screw conveyor to pick up and discharge sinking materials. Next, we have a friction washer that rotates at 1000 RPM spin out contaminants and debris. At the end of washing, a centrifugal dryer carries out the dewatering, minizing the water content to 1%.

Soft pvc shoes crushing washing recycling line manufacture

Project parameters

Model	Capacity	Installation power	Space	Steam	Compressed air	water
PVC500	500kg/h	90kw	500m2		0.5m3	1m3
PVC1000	1000kg/h	158kw	1500m2		0.5m3	1m3
PVC2000	2000kg/h	238kw	2000m2		0.5m3	2m3
